Wash Out Urinal in White
Zurn
The Retrofit Pint® Wash Out Urinal in White
Package Quantity Info:
Each: 1 Inner Pack: 1 Case: 4 Pallet: 20Quantity:
The quantity entered must be a multiple of 1 – for example, 1, 2, 3, and so on.
How to get it:
-
-
Shipping AvailableAvailable for immediate shipment
Purchase history
Zurn
The Retrofit Pint®
Wash Out Urinal in White
Z5758-U
Order #
Order Date
Job Name
My PO#
Shows all online and in-store purchases made within the past 12 months.
Product Details
Product Description
- High-efficiency washout action increases flushing power
- Pressure-compensating internal flow regulator improves flush performance
- Durable vitreous China resists stains and scratches
- ¾” top spud
- 2” I.P.S. outlet flange and rubber gasket with integral trap
- Vandal-resistant outlet strainer
- Oversized footprint covers previous equipment marks for simplified retrofit installation
- Easily retrofits 4-bolt pattern urinals without work behind the finished wall (includes bracket)
- 14” extended rim
- ADA compliant when installed at proper height
Product Information
-
ADA Compliant
-
Green
Dimensions & Measurements
Depth
18-1/2 in
End Connection 1
NPSM
End Connections
NPSM
Flow Rate
0.125 gpf
Flow Rate Range
0.125 gpf - 1.0 gpf
Height
29 in
Inlet Spud Size
3/4 in
Length
18-1/2 in
Outlet Spud Size
2 in
Width
14-1/4 in
Characteristics & Features
Collection
The Retrofit Pint®
Color Finish Category
Whites
Color Finish Name
White
Flush Type
Washdown
Inlet Spud Location
Top
Material
Vitreous China
Proposition 65
WARNING: Cancer and Reproductive Harm - www.P65Warnings.ca.gov
Urinal Installation
Wall Mount
Warranty & Product Information
ADA Compliant
Yes
ANSI
ANSI A117.1
ASME
ASME A112.19.2
BAA Compliant
No
CARB OTC LEED Compliant
No
CEC Compliant
For Sale in CA
CSA Certified
CSA B45.1
GSA Approved
No
IAPMO Listed
No
WaterSense Labeled
Yes
UPC
670240396814
